Saginaw Control & Engineering
SCE-N68EXD6618SS - S.S. 2DR Enc. Both sides Solid- Provisions for EXD
$14,140.09
- Height
- 68.00"
- Width
- 66.50"
- Depth
- 18.00"
- Est. Ship Weight
- 420.89 lbs
Product information
Technical details
S.S. 2DR Enc. Both sides Solid- Provisions for EXD
Category: NextGen Free-Standing (304 and 316 Stainless Steel) > NextGen Free Standing (304 Stainless Steel) > NextGen Free-Standing Enclosures with Provisions for External Disconnect (304 Stainless Steel) > NextGen Free-Standing Two-Door Enclosures Both Sides Solid with Provisions for External Disconnect (304 Stainless Steel)
Specifications
| Part Number | SCE-N68EXD6618SS |
|---|---|
| Description | S.S. 2DR Enc. Both sides Solid- Provisions for EXD |
| Height | 68.00" |
| Width | 66.50" |
| Depth | 18.00" |
| Price Code | S2 |
| List Price | $14,140.09 |
| Catalog Page | 999 |
| Est. Ship Weight | 420.89 lbs |
Construction
- Provisions for external disconnect.
- Both sides solid.
- .104 in stainless steel Type 304.
- Seams coninously welded and ground smooth.
- Flange trough collar around all sides of door opening
- Body stiffeners in large enclosures for extra rigidity
- Heavy duty lifting eyes anchor into reinforced top.
- Concealed hinges.
- 3-point latching mechanism
- End of latch rods have ramp shoes for easier door closing.
- Panel supports.
- Pour in place oil & water resistant gasket
- Optional panels mount to collar studs.
- Ground stud on door & body
- Provisions for light kit.
- Black zinc die cast coinproof/padlocking handle on door.
Application
Designed to house a variety of electrical and electronic controls and instruments, and most standard type disconnects. Provides protection from dust, dirt, water and oil. Provisions for external disconnect.
Finish
#4 brushed finish on all exterior surfaces. Optional subpanels powder coated white or galvanized.
Industry Standards - (IS6)
- NEMA Type 3R, 4, 4X, 12 and Type 13
- UL Listed Type 3R, 4, 4X and 12
- CSA Type 4, 4X and 12
- IEC 60529
- IP 66
