SCE-N86L4018SS6 - S.S. 1DR Enc. Left Bay - Right Side Open

$11,305.27

Height: 86.00"
Width: 40.25"
Depth: 18.00"
Est. Ship Weight: 425.00 lbs

Request freight quote

Ships by freight. Request a quote and we'll confirm shipping and lead time.

S.S. 1DR Enc. Left Bay - Right Side Open

Category: NextGen Free-Standing (304 and 316 Stainless Steel) > NextGen Free Standing (316 Stainless Steel) > NextGen Free-Standing - Left Bay (316 Stainless Steel) > NextGen Free-Standing Single-Door Enclosures Left Bay - Right Side Open (316 Stainless Steel)

Specifications

Part Number	SCE-N86L4018SS6
Description	S.S. 1DR Enc. Left Bay - Right Side Open
Height	86.00"
Width	40.25"
Depth	18.00"
Price Code	S2
List Price	$11,305.27
Catalog Page	294
Est. Ship Weight	425.00 lbs

Construction

.104 in stainless steel Type 316.
Seams continuously welded and ground smooth.
Flange trough collar around all sides of door opening.
Body stiffeners in large enclosures for extra rigidity.
Heavy duty lifting eyes anchor into reinforced top.
Concealed hinges.
Black zinc die cast padlocking handles on doors.
3-point latching mechanism.
End of latch rods have ramp shoes for easier door closing.
Panel supports.
Pour-in-place oil & water resistant gasket.
Optional panels mount to collar studs.
Ground stud on door and body.
Provisions for light kit.
Enclosures include provisions for system expansion.

Application

Can be bolted together in any desired multiple door arrangement for maximum versatility. Designed to house a variety of electrical and electronic controls and instruments. Provides protection from dust, dirt, water and oil. The enclosures are extra deep for applications requiring more interior space. For outdoor application a drip shield and drain vent is recommended.
