SCE-N80C7824 - 2DR Enc. Center Bay - Both Side Open

$4,130.52

Height: 80.00"
Width: 77.75"
Depth: 24.00"
Est. Ship Weight: 811.00 lbs

Request freight quote

Ships by freight. Request a quote and we'll confirm shipping and lead time.

2DR Enc. Center Bay - Both Side Open

Category: NextGen Free-Standing > NextGen Free-Standing - Center Bay > NextGen Free-Standing Two-Door Enclosures Center Bay - Both Sides Open

Specifications

Part Number	SCE-N80C7824
Description	2DR Enc. Center Bay - Both Side Open
Height	80.00"
Width	77.75"
Depth	24.00"
Price Code	A2
List Price	$4,130.52
Catalog Page	174
Est. Ship Weight	811.00 lbs

Construction

.104 in carbon steel.
Seams continuously welded and ground smooth.
Flange trough collar around all sides of door opening.
Body stiffeners in large enclosures for extra rigidity.
Heavy duty lifting eyes anchor into reinforced top.
Black zinc die cast padlocking handles on doors.
3-point latching mechanism.
End of latch rods have ramp shoes for easier door closing.
Panel supports.
Pour-in-place oil & water resistant gasket.
Optional panels mount to collar studs.
Ground stud on door and body.
Provisions for light kit.
Holes plug provided to seal holes in bottom of enclosure.
Enclosures include provisions for system expansion.

Application

Can be bolted together in any desired multiple door arrangement for maximum versatility. Designed to house a variety of electrical and electronic controls and instruments. Provides protection from dust, dirt, water and oil. The enclosures are extra deep for applications requiring more interior space. For outdoor application a drip shield and drain vent is recommended.
