Saginaw Control & Engineering
SCE-N12FA66-24VDC - Filter Fan. (24VDC)
$585.98
- Height
- 9.84"
- Width
- 9.84"
- Depth
- 4.40"
- Est. Ship Weight
- 4.00 lbs
Product information
Technical details
Filter Fan. (24VDC)
Category: Thermal Management > Air To Air > Type 12 Fan/Filter Package > Type 12 Fans and Filters - Black > Type 12 Fans and Filters - Black
Specifications
| Part Number | SCE-N12FA66-24VDC |
|---|---|
| Description | Filter Fan. (24VDC) |
| Height | 9.84" |
| Width | 9.84" |
| Depth | 4.40" |
| Price Code | P1 |
| List Price | $585.98 |
| Catalog Page | 398 |
| Est. Ship Weight | 4.00 lbs |
| Model | 4611D2003-S |
| Voltage | 24V DC |
| CFM | 86 |
| Current (A) | 0.71 |
Application
Easy to install snap fit design for use in enclosures that require cooling but have limited space in NEMA 1 and 12 applications. Housing and grille are made of black heat resistant (ABS-FR), self-extinguishing material. Fans are available in 115 or 230 volt AC, 60/50 Hertz (HZ) single phase or 24 volt DC. Filter Class G3 EN 779 - Filter Fire Class F1 DIN 53438 Self-extinguishing.
Industry Standards - (IS24)
- UL Component Recognized
Notes
Type 12 - IEC 60529 IP 54 cULus Listed E498756 cULus File Component Recognized E358386 Motor w/ Thermal Protection
