Saginaw Control & Engineering
SCE-FEG1010LG - Filter Exaust Grille. Type 3R, 12 RAL 7035
- Height
- 12.72"
- Width
- 12.72"
- Depth
- 1.75"
- Est. Ship Weight
- 1.25 lbs
Product information
Technical details
Filter Exaust Grille. Type 3R, 12 RAL 7035
Category: Thermal Management > Air To Air > Type 3R/12 Fans and Filters > Type 3R/12 Filter Exhaust Grille Light Gray
Specifications
| Part Number | SCE-FEG1010LG |
|---|---|
| Description | Filter Exaust Grille. Type 3R, 12 RAL 7035 |
| Height | 12.72" |
| Width | 12.72" |
| Depth | 1.75" |
| Price Code | P1 |
| List Price | $108.62 |
| Catalog Page | 999 |
| Est. Ship Weight | 1.25 lbs |
Application
Easy to install snap fit design with hinged cover for use in enclosures that require cooling but have limited space in NEMA 1, 3R and 12 applications. Grille UV and water resistant, self-extinguishing PVC material, housing is made of ABS material . Fans are available in 115 or 230 volt AC, 60/50 Hertz (HZ) single phase or 24 volt DC. 500 CFM Available in 460 volt AC - Filter Class G3 EN 779 - Filter Fire Class F1 DIN 53438 Self-extinguishing.
Industry Standards - (IS24)
- UL Component Recognized
Notes
Type 12 - IEC 60529 IP 54 cULus Listed E498756 cULus File Component Recognized E358386 Motor w/ Thermal Protection
