SCE-90XML2D18 - 2DR Left XM Enclosure

2DR Left XM Enclosure

Category: Free-Standing and Floor-Mounted Enclosures > Heavy Duty Free-Standing Enclosures for Flange-Mounted Disconnects (One through Six Door Enclosures) > Heavy Duty Free-Standing Left Enclosures

Specifications

Construction

• 0.125 in. carbon steel.
• Seams continuously welded and ground smooth.
• Flange trough collar around all sides of door opening.
• Body stiffeners in large enclosures for extra rigidity.
• Heavy duty lifting eyes anchor into reinforced top.
• Removable centerposts permit easy panel installation.
• Concealed hinges.
• Black zinc die cast padlocking handles on doors.
• 3-point latching mechanism.
• Ends of latch rods have ramp shoes for easier door closing.
• Panel supports.
• Pour in place oil & water resistant gasket
• Removable panels mount to collar studs.
• Ground stud on door and body.
• Provisions for light kit.
• Holes plugs provided to seal holes in bottom of enclosure.

Application

This enclosure is designed to be the left most enclosure in a larger multi-door enclosure. Designed to house electrical equipment and provide protection from dirt, dust, oil and water and to house most standard type disconnects. For outdoor application a drip shield and drain vent is recommended. For details about the design, performance expectations, applications and design suggestions -

Finish

ANSI-61 gray powder coating inside and out. Sub-panels are powder coated white. Part numbers ending in "G" have galvanized subpanels installed.

Industry Standards - (IS3)

• NEMA Type 3R, 12 and Type 13
• UL Listed Type 3R and 12
• CSA Type 3R and 12
• IEC 60529
• IP 55

Notes

*Part numbers ending in "G" have galvanized sub-panels installed. Special Instructions apply for IS3, IS4 and IS6 to maintain the environmental rating of Type 3R for these parts. Instructions are located on the enclosure door. Drip shield is required on IS3, drip shield is recommended on IS4 and IS6. Drain holes are required on all
