Saginaw Control & Engineering
SCE-84XM4018SS - S.S. 1DR XM Enclosure
- Height
- 84.00"
- Width
- 39.50"
- Depth
- 18.00"
- Est. Ship Weight
- 500.00 lbs
Product information
Technical details
S.S. 1DR XM Enclosure
Category: Free-Standing and Floor-Mounted Enclosures (Stainless Steel) > Heavy Duty Free-Standing Enclosures for Flange Mounted Disconnects One through Six Door Enclosures (Stainless Steel) > Single-Door Stainless Steel Enclosures
Specifications
| Part Number | SCE-84XM4018SS |
|---|---|
| Description | S.S. 1DR XM Enclosure |
| Height | 84.00" |
| Width | 39.50" |
| Depth | 18.00" |
| Price Code | S2 |
| List Price | $10,169.89 |
| Catalog Page | 318 |
| Est. Ship Weight | 500.00 lbs |
Construction
- 0.104 In. stainless steel Type 304.
- Seams continuously welded and ground smooth.
- Flange trough collar around all sides of door opening.
- Body stiffeners in large enclosures for extra rigidity.
- Heavy duty lifting eyes anchor into reinforced top.
- Stainless steel concealed hinges.
- Black zinc die cast coinproof/padlocking handle.
- 3-point latching mechanism.
- Ends of latch rods have ramp shoes for easier door closing.
- Panel supports.
- Large removable print pockets.
- Pour in place oil & water resistant gasket
- Removable panels mount on collar studs.
- Defeater on master door requires a screwdriver to open.
- Ground stud on door.
- Provisions for light kit.
Application
Designed to house electrical equipment and provide protection from dirt, dust, oil and water and to house most standard type disconnects. For outdoor application a drip shield and drain vent is recommended. For details about the design, performance expectations, applications and design suggestions -
Finish
#4 brushed finish on all exterior surfaces. Sub-panels are powder coated white.
Industry Standards - (IS6)
- NEMA Type 3R, 4, 4X, 12 and Type 13
- UL Listed Type 3R, 4, 4X and 12
- CSA Type 4, 4X and 12
- IEC 60529
- IP 66
Notes
Disconnect switch (or circuit breaker) and operating mechanism are not furnished with enclosure. Special Instructions apply for IS3, IS4 and IS6 to maintain the environmental rating of Type 3R for these parts. Instructions are located on the enclosure door. Drip shield is required on IS3, drip shield is recommended on IS4 and IS6. Drain holes are required on all.
