SCE-72EL7218SSST - S.S. 2DR EL Sloping Top Enclosure

$18,860.44

Height: 72.00"
Width: 72.00"
Depth: 18.00"
Est. Ship Weight: 783.00 lbs

Request freight quote

Ships by freight. Request a quote and we'll confirm shipping and lead time.

S.S. 2DR EL Sloping Top Enclosure

Category: Free-Standing and Floor-Mounted Enclosures (Stainless Steel) > Enviroline Series Sloping Top Two-Door Enclosure (Stainless Steel)

Specifications

Part Number	SCE-72EL7218SSST
Description	S.S. 2DR EL Sloping Top Enclosure
Height	72.00"
Width	72.00"
Depth	18.00"
Price Code	S8
List Price	$18,860.44
Catalog Page	304
Est. Ship Weight	783.00 lbs

Construction

0.104 In. stainless steel Type 304.
Seams continuously welded and ground smooth.
Flange trough collar around all sides of door opening.
15 degree sloping top.
Removable center post.
Heavy duty lifting eyes anchor into reinforced top.
Body stiffeners.
Stainless Steel concealed hinges.
Stainless Steel padlocking handles.
3-point latching mechanism.
Removable print pocket.
Provisions for 12in. removable floor stands.
Panel Supports.
Pour in place oil & water resistant gasket
Ground stud on door and body.
Provisions for light kit.
Collar studs 3/8-16 provided for mounting optional panels.

Application

Designed to house electrical and electronic controls, instrumentation and components in indoor, outdoor and sanitary locations. For Details about the Design, Performance Expectations, Applications and Design Suggestions -

Finish

#4 brushed finish on all exterior surfaces. Optional sub-panels are powder coated white.

Industry Standards - (IS6)

NEMA Type 3R, 4, 4X, 12 and Type 13
UL Listed Type 3R, 4, 4X and 12
CSA Type 4, 4X and 12
IEC 60529
IP 66

Notes

Special Instructions apply for IS3, IS4 and IS6 to maintain the environmental rating of Type 3R for these parts. Instructions are located on the enclosure door. Drip shield is required on IS3, drip shield is recommended on IS4 and IS6. Drain holes are required on all.
