SCE-72EL7212LPPL - 2DR EL LPPL Enclosure

2DR EL LPPL Enclosure

Category: Free-Standing and Floor-Mounted Enclosures > Enviroline Series Two-Door Enclosures

Specifications

Construction

• 0.104 In. carbon steel.
• Seams continuously welded and ground smooth.
• Flange trough collar around all sides of door opening.
• Removable centerpost.
• Heavy duty lifting eyes anchored into reinforced top.
• Body stiffeners.
• Concealed hinges.
• Black keylocking padlocking handles.
• 3-point latching mechanism.
• Removable print pocket.
• 12 In. removable floor stands.
• Panel Supports.
• Provisions for mechanical interlock.
• Pour in place oil & water resistant gasket
• Ground stud on door and body.
• Provisions for light kit.
• Hole plugs provided to seal holes in bottom of enclosure.
• Collar studs 3/8-16 provided for mounting optional panels.

Application

Designed to house electrical and electronic controls, instrumentation and components in indoor & outdoor locations. For outdoor application a drip shield and drain vent is recommended. For details about the design, performance expectations, applications and design suggestions -

Options

Provisions for mechanical interlock. See Accessory section to order.

Finish

ANSI-61 gray powder coating inside and out. Optional sub-panels are powder coated white.

Industry Standards - (IS4)

• NEMA Type 3R, 4, 12 and Type 13
• UL Listed Type 3R, 4 and 12
• CSA Type 3R, 4 and 12
• IEC 60529
• IP 66

Notes

Special Instructions apply for IS3, IS4 and IS6 to maintain the environmental rating of Type 3R for these parts. Instructions are located on the enclosure door. Drip shield is required on IS3, drip shield is recommended on IS4 and IS6. Drain holes are required on all.
