SCE-65XVR3716 - Enclosure, Vented Type 3R Disconnect

$2,652.36

Height: 65.00"
Width: 37.38"
Depth: 16.00"
Est. Ship Weight: 277.67 lbs

Request freight quote

Ships by freight. Request a quote and we'll confirm shipping and lead time.

Enclosure, Vented Type 3R Disconnect

Category: Wall-Mount Enclosures > Vented Type 3R Disconnect Enclosures

Specifications

Part Number	SCE-65XVR3716
Description	Enclosure, Vented Type 3R Disconnect
Height	65.00"
Width	37.38"
Depth	16.00"
Price Code	N3
List Price	$2,652.36
Catalog Page	110
Est. Ship Weight	277.67 lbs
System CFM	600
Volt	120 VAC

Construction

0.075 In. Galvannealed Steel.
3-point latching mechanism.
Collar studs 3/8-16 provided for mounting optional panels.
Doors open 180 degrees.
Disconnect cutout provided on flange.
Vented top hood with bug screen.
Top mounted fans.
Vented rain hood with filter kits in door.
Din Rail mounting provisions inside top for installation of thermostat and terminals.
Pour in place oil & water resistant gasket
Ground stud on door and body.
Mounting Holes for optional mounting straps.
3/8-16 grounding kit.
Subpanel mounting hardware.
Concealed hinges.

Application

Designed to house electrical controls, drives, instruments and components used in an outdoor environment to provide a degree of protection for the equipment inside the enclosure against ingress of solid foreign objects (falling dirt); and provide a degree of protection with respect to the harmful effects on the equipment due to the ingress of water (rain, sleet, snow). Designed to house most standard disconntects. For Details about the Design, Performance Expectations, Applications and Design Suggestions -
