Saginaw Control & Engineering
SCE-642424WS - Workstation
$2,895.61
- Height
- 64.00"
- Width
- 24.25"
- Depth
- 24.25"
- Est. Ship Weight
- 285.00 lbs
Product information
Technical details
Workstation
Category: Operator System Enclosures > Work Stations
Specifications
| Part Number | SCE-642424WS |
|---|---|
| Description | Workstation |
| Height | 64.00" |
| Width | 24.25" |
| Depth | 24.25" |
| Price Code | C2 |
| List Price | $2,895.61 |
| Catalog Page | 32 |
| Est. Ship Weight | 285.00 lbs |
Construction
- 0.075 In. carbon steel.
- Seams continuously welded and ground smooth.
- Pour in place oil & water resistant gasket
- Flange trough collar around all sides of door opening.
- Concealed hinges.
- Removable doors.
- Ground studs on door and body.
- Large polycarbonate viewing window in top door.
- Lifting eyes for easy handling.
- Rubber pads with provision for leveling pads on bottom of enclosure.
- Black, quarter turn latches on top door.
- Black, quarter turn wing knob latches.
- Black 3-point key locking flush swing handle in lower front and back doors.
- Gland plate on lower back of enclosure.
- Pull out keyboard shelf with attached self storing mouse shelf and mouse pad.
- Mounting channels welded on sides of interior body for mounting optional panels, racks, mounting angles and shelves.
Application
Designed to house a computer, keyboard, monitor and other additional computer equipment in an industrial environment and provide protection from dust, oil and moisture. For Details about the Design, Performance Expectations, Applications and Design Suggestions -
Options
Optional tamper-resistant inserts or padlocking handles are available.
Finish
RAL 7035 gray powder coating inside and out.
Industry Standards - (IS1)
- NEMA Type 12 and Type 13
- UL Listed Type 12
- CSA Type 12
- IEC 60529
- IP 55
Notes
Optional panels and accessories are available.
