Saginaw Control & Engineering
SCE-36EL3012SS6LPPL - S.S. LPPL Enclosure
- Height
- 36.00"
- Width
- 30.00"
- Depth
- 12.00"
- Est. Ship Weight
- 111.00 lbs
Product information
Technical details
S.S. LPPL Enclosure
Category: Wall-Mount Enclosures (Stainless Steel) > Enviroline Series Single-Door Enclosures With 3 Point Hardware (304 and 316 Stainless Steel) > Enviroline Series Single-Door Enclosures With 3 Point Hardware (316 Stainless Steel)
Specifications
| Part Number | SCE-36EL3012SS6LPPL |
|---|---|
| Description | S.S. LPPL Enclosure |
| Height | 36.00" |
| Width | 30.00" |
| Depth | 12.00" |
| Price Code | S9 |
| List Price | $2,970.12 |
| Catalog Page | 254 |
| Est. Ship Weight | 111.00 lbs |
Construction
- 0.075 In. stainless steel Type 316/316L.
- Seams continuously welded and ground smooth.
- Flange trough collar around all sides of door opening
- Collar studs 3/8-16 provided for mounting optional panels.
- Mounting holes in back of enclosure for wall mounting.
- Mounting hardware, sealing washer and hole plug included.
- Stainless steel concealed hinges.
- Removable and inchangeable doors.
- Black zinc die cast keylocking/padlocking handle.
- 3-point latching mechanism.
- Removable print pocket.
- Pour in place oil & water resistant gasket
- Ground stud on door and body.
Application
Designed to house electrical and electronic controls, instrumentation and components in indoor or outdoor locations. For outdoor applications a drip shield is recommended. For outdoor application a drip shield is recommended. For Details about the Design, Performance Expectations, Applications and Design Suggestions -
Finish
#4 Brushed finish on all exterior surfaces. Optional sub-panels are powder coated white.
Industry Standards - (IS6)
- NEMA Type 3R, 4, 4X, 12 and Type 13
- UL Listed Type 3R, 4, 4X and 12
- CSA Type 4, 4X and 12
- IEC 60529
- IP 66
Notes
Special Instructions apply for IS3, IS4 and IS6 to maintain the environmental rating of Type 3R for these parts. Instructions are located on the enclosure door. Drip shield is required on IS3, drip shield is recommended on IS4 and IS6. Drain holes are required on all. Provision for Lifting Lugs on enclosures when Height >48" and Depth >16". The Lifting Lug assembly will be included with the enclosure bolt pack.
