Saginaw Control & Engineering
SCE-10PBX - PBX Enclosure
$141.17
- Height
- 14.00"
- Width
- 6.25"
- Depth
- 4.75"
- Est. Ship Weight
- 11.00 lbs
Product information
Technical details
PBX Enclosure
Category: Wall-Mount Enclosures > Pushbutton Enclosures and Hinged Pushbutton Enclosures > Extra Deep 30.5 mm Pushbutton Enclosures
Specifications
| Part Number | SCE-10PBX |
|---|---|
| Description | PBX Enclosure |
| Height | 14.00" |
| Width | 6.25" |
| Depth | 4.75" |
| Price Code | A1 |
| List Price | $141.17 |
| Catalog Page | 60 |
| Est. Ship Weight | 11.00 lbs |
Construction
- 0.063 In. carbon steel
- Continuously welded seams
- Captivated cover screws thread into sealed wells
- 4-way standard pushbutton holes accept all brands of oil-tight pushbuttons, switches, and pilot lights. Hole diameter is 1.20 In. (30.5 mm)
- Immediate removal of cover is still permitted
- Pour in place oil & water resistant gasket
- Welded mounting provision top and bottom of back
Application
Designed to offer protection for oil-tight pushbuttons, switches, and pilot lights from dust, water, dirt and oil.
Finish
ANSI-61 gray powder coating inside and out.
Industry Standards - (IS2)
- NEMA Type 4, 12 and Type 13
- UL Listed Type 4 and 12
- CSA Type 4 and 12
- IEC 60529
- IP 66
Notes
Add ''I'' to catalog number to receive with 22.5mm hole diameter
