ELCO
NI4-M12-LIU Inductive Sensor
$68.96
- Cable length
- 2 m
- Sensing range
- 4 mm
- Output type
- Current + Voltage
- Supply voltage
- 10 ... 30 V DC
Product information
Technical details
Inductive Sensors, Analog output type, Threaded cylindrical housing M12, Switching distance 0.8 ... 4 mm, Non-flush, IP67, -25 ... 70 °C, 0 ... 20 mA & 0 ... 10 V DC, 2 m cable
Specifications
MPN NI4-M12-LIU
| Connection | Cable |
|---|---|
| Cable type | PVC |
| Sensing range | 4 mm |
| Sensing surface material | PBT |
| Housing material | Nickel-plated brass |
| Switching frequency | 800 Hz |
| Supply voltage | 10 ... 30 V DC |
| Ambient temperature | -25 … +70 ℃ |
| External dimensions | M12 x 1 |
| Output type | Current + Voltage |
| Mounting | Non-flush |
| Product size | M12 x 51.2 mm |
| Cable length | 2 m |
| IP rating | IP67 |
